英國GRIMM格林進口三柱塞高壓隔膜往復泵 UK GRIMMImported three plunger high pressure diaphragm reciprocating pump

英國GRIMM格林進口三柱塞高壓隔膜往復泵概述：

進口三柱塞高壓隔膜往復泵是英國格林為適應市場需求，按照國際標準API674標準設計，許多專利一直代表著世界先進水平。產品滿足極為苛刻的工況要求，能精準可靠地輸送物料，滿足這一類型泵產品的最高要求。
具有緊湊結構的往復泵在設備制造領域尤為受到青睞，這得益于英國格林扎實的技術基礎。過程隔膜泵的設計確保在輸送苛刻、有毒、可燃或腐蝕介質時絕無泄露，而不受各個領域不同要求的限制。

英國GRIMM格林進口三柱塞高壓隔膜往復泵特點：

產品特點：

1、模塊化結構，結構緊湊，體積小，重量輕；
2、潤滑性好，摩擦系數小，效率高；
3、動力端傳動平穩可靠、噪音小；
4、組裝形式：臥式、立式、固定式、移動式；
5、動力源：電動機、柴油機、太陽能；
6、減速機型式：雙斜齒輪式、蝸輪蝸桿式、減速機式、皮帶輪式；
7、過流材料有合金鋼、不銹鋼、雙相鋼、鈦、哈氏合金等；
8、根據客戶要求個性化設計。

雙斜齒輪減速機構的特點：
1、低軸力，自我調整，軸承使用壽命長；
2、特殊的柱塞定線設計和 短小的十字頭設計，結構緊湊，傳輸精度高；
3、雙斜齒輪提供了非常簡潔的設計和最大效率，這種設計使占用面積最小化和功率最低化；
4、由于設計帶有雙斜齒輪，使得曲柄軸和小齒輪軸免于軸的負載，平調的傳輸裝置使得壽命長和低噪音；
5、曲柄軸經鍛造和噴丸硬化處理，減小應力，使得結構堅固，疲勞強度高；
6、往復的壓力推進潤滑油作用于十字頭銷和連桿滑動軸承，不需要額外的潤滑系統；
7、齒輪由壓力和溫度開關檢測，因此預防了低油位和超載；
8、所有油密封可以從外部維修從而使得維修簡便，維修不需要放油。
柱塞式液力端的特點：
1、柱塞采用航空金剛玉噴涂工藝，摩擦小，硬度高；密封采用進口盤根配合特殊的內隔套結構，降低液力端的泄露。
2、模塊化設計，不拆泵頭，管路即可直接更換填料，柱塞，單向閥，大大降低了用戶的維護成本。
3、雙導向組合閥組，由耐磨耐腐材料制成，采用真空淬火工藝，工作準確，分為迅速，壽命長。
4、采用彈簧驅動密封填料，使得密封效果好，使用壽命長。
過程隔膜式液力端的特點：
過程隔膜泵是英國格林在原有先進計量泵的結構基礎上研制而成，產品融合了液壓隔膜泵及柱塞泵的優點，結構緊湊、效率高、承載壓力高，克服柱塞泵易腐蝕、易泄露的缺點。
1、采用隔膜將輸送介質和液壓油完全隔開，保證絕無泄露。適用于有腐蝕性、劇毒性、精度要求比較高的場合。
2、排氣閥可以自動放出隔膜腔及油箱內的空氣。
3、補償閥能及時補充隔膜腔內的液壓油，保持隔膜腔的油量穩定，確保泵的計量精度。
4、液壓驅動油路采用全封閉式設計，杜絕灰塵雜物侵入及人員操作時損壞油路的暢通和安全。
5、雙隔膜泵：具有隔膜泵的一切優點，并具備隔膜破裂檢測裝置，，在一片隔膜破裂的情況下，另一片膜片可繼續工作，同時隔膜破裂檢測裝置可發出報警信號，適用于輸送有毒、易燃易爆及強腐蝕等危險介質。
6、金屬液壓隔膜式泵頭，用于高溫、高壓場合，最高使用溫度可達451℃，壓力可達70MPa。
變頻調節，通過變頻器調節電機電源的頻率，控制電機的轉速，從而改變泵的次數來調節泵的流量。
多聯往復泵的特點：
1、多泵頭設計，有效降低脈沖，更適用于大流量高壓力，長期穩定運行。
2、模塊化設計，不拆泵頭及管路，可以直接更換填料，大大降低用戶的維護成本。
3雙斜齒輪提供了非常簡潔的設計和最大效率，這種設計占用面積最小化和功率最低化。
4、可根據工況需要做成多泵頭高壓力的過程隔膜泵。
星型立式往復泵的特點：
1、該泵采用了單拐曲軸驅動環狀分布的往復傳動組件立式結構，結構簡單，易于加工，絕無泄露。
2、承載力大，使用壽命長，穩定性強，維修方便。
3、機械效率高，摩擦小，節能環保。
4、多方位立體化安裝，不受空間限制，更適合海上平臺、油氣田等。
5、亦稱為直立工作的多柱塞高壓往復泵。

英國GRIMM格林進口三柱塞高壓隔膜往復泵技術參數：

流量范圍：0.1-83m3/h
工作壓力：0-80MPa
電機功率：0.75-450kw
泵 行 程：40-175mm
柱塞直徑：15-88mm

英國GRIMM格林進口三柱塞高壓隔膜往復泵應用：

適用于做管道清洗、工件清洗、表面清洗、清砂、除銹、液體輸送、液體傳動、工程掘進等，以及各種膠管、金屬管、油田鉆井井口設備試壓用泵，即可泵送清水、乳化液，亦能泵送其它具有化學性質的液體。

UK GRIMMImported three plunger high pressure diaphragm reciprocating pumpsummary:

Imported three plunger high pressure diaphragm reciprocating pump is the United Kingdom Green in order to meet market demand, according to international standards, API674 standard design, many patents have been representing the world advanced level. Products to meet the extremely demanding conditions, accurate and reliable delivery of materials to meet the highest requirements of this type of pump products.

The reciprocating pump with a compact structure is especially popular in the field of equipment manufacturing, thanks to the solid technical foundation of Green. The design of the process diaphragm pump ensures no leakage in harsh, poisonous, flammable or corrosive media without restriction from various fields.

UK GRIMMImported three plunger high pressure diaphragm reciprocating pump characteristic:

Product features:

1. Modular structure, compact structure, small size, light weight;

2. Good lubricity, low friction coefficient and high efficiency;

3. The power transmission is stable and reliable with little noise;

4. Assembly forms: horizontal, vertical, fixed, mobile;

5. Power source: motor, diesel engine, solar energy;

6. Deceleration type: double helical gear, worm gear, gear reducer, belt wheel type;

7. Over current materials include alloy steel, stainless steel, dual phase steel, titanium and Hastelloy alloy;

8. Personalized design according to customer requirements.

Features of double helical gear reduction mechanism:

1. Low axial force, self adjustment, long bearing life;

2. Special plunger alignment design and short cross head design, compact structure, high transmission accuracy;

3. Double helical gears provide very compact design and maximum efficiency. This design minimizes footprint and power minimization;

4. Because of the design with double helical gears, the crank shaft and the pinion shaft from the shaft load transmission device makes the level of long life and low noise;

5. The crankshaft is treated by forging and shot peening, which reduces the stress and makes the structure strong and the fatigue strength high;

6. Reciprocating pressure boosting lubricating oil acts on crosshead pin and connecting rod sliding bearing without additional lubrication system;

7. The gear is detected by pressure and temperature switch, so low oil level and overload are prevented;

8. All oil seals can be maintained externally so that maintenance is simple and no oil is required for maintenance.

Characteristics of plunger type hydraulic end:

1. The plunger adopts the aviation diamond spraying process, small friction, high hardness; sealed imported packing, with special internal separation sleeve structure, reducing the leakage of hydraulic side.

2. Modular design, without dismantling the pump head, the pipeline can be directly replaced by packing, plunger, one-way valve, greatly reducing the user's maintenance costs.

3. Double guiding combination valve, made of wear-resistant and corrosion-resistant material, adopts vacuum quenching technology. The work is accurate, divided into quick and long life.

4. The use of spring driven sealing filler, so that the sealing effect is good, long service life.

The characteristics of the diaphragm hydraulic end:

The process of diaphragm pump is based on the original structure of the British Green advanced metering pump on the development, the product combines the advantages of hydraulic diaphragm pump and piston pump, compact structure, high efficiency, high bearing pressure,overcome piston pump corrosion, leakage faults.

1. The use of diaphragm, the transmission medium and hydraulic oil completely separated, to ensure that no leakage. The utility model is suitable for occasions with corrosive, poisonous and high precision requirements.

2. The exhaust valve can automatically release the air in the diaphragm cavity and the tank.

3. The compensation valve can be added in time to the diaphragm cavity hydraulic oil, to maintain the diaphragm cavity oil volume stability, to ensure the accuracy of the pump measurement.

4. Hydraulic drive oil circuit adopts full closed design, prevent dust, sundries invasion and personnel operation, damage to the smooth and safety of the oil circuit.

5. Double diaphragm pump has all the advantages of the diaphragm pump, and has the detection device in a diaphragm rupture, rupture of diaphragm case, another diaphragm can continue to work at the same time the diaphragm rupture detection device can send out alarm signals, suitable for conveying toxic, flammable and corrosive dangerous medium.

6. Metal hydraulic diaphragm pump head, used in high temperature, high pressure occasions, the maximum use temperature of 451 degrees, the pressure of up to 70MPa.

Variable frequency regulation, through the frequency converter to adjust the motor power frequency, control the speed of the motor, thereby changing the number of pumps to adjust the flow of the pump.

Characteristics of multiple reciprocating pumps:

1. Multi pump head design, effectively reduce the pulse, more suitable for large flow, high pressure, long-term stable operation.

2. Modular design, without dismantling the pump head and piping, you can directly replace the filler, greatly reducing the user's maintenance costs.

3. Double helical gears provide very compact design and maximum efficiency, this design minimizes area and minimizes power.

4. According to the process of diaphragm pump condition made of multi pump pressure head.

Characteristics of star vertical reciprocating pump:

1. The pump adopts a single crank driven ring distribution of reciprocating transmission components, vertical structure, simple structure, easy to process, no leakage.

2. Bearing capacity, long service life, stability, convenient maintenance.

3. High mechanical efficiency, small friction, energy saving and environmental protection.

4. Multi-directional three-dimensional installation, free from space constraints, more suitable for offshore platforms, oil and gas fields.

5. Also known as the vertical work of multi plunger high-pressure reciprocating pump.

UK GRIMMImported three plunger high pressure diaphragm reciprocating pumptechnical parameter:

Flow range: 0.1-83m3/h

Work pressure: 0-80MPa

Motor power: 0.75-450kw

Pump stroke: 40-175mm

Plunger diameter: 15-88mm

UK GRIMMImported three plunger high pressure diaphragm reciprocating pumpapplication:

Suitable for oil field water injection pump, injection pump, feeding pump, butylene glycol ammonium carbamate pump, liquid ammonia pump, copper acetate, ammonia pump pump, liquid carbon dioxide phosphate amine alcohol injection pumps, pump, oil refining and hydrogenation of coal water slurry pump, diaphragm pump, tubing cleaning pump, pump, high pressure and ultra high pressure chemical cleaning pump, flow pump, salt water injection pump, liquid methanol pump and metallurgy with high-pressure water descaling pump, hydraulic machine with high pressure pump etc..
